Download the comprehensive mechanical drawing for a Communication Optical Cable Enclosure, a critical component for modern fiber optic networks. This type of enclosure, often called a Fiber Optic Splice Closure (FOSC) or termination box, is engineered to protect and organize delicate fiber optic splices from the harsh outdoor environment. It is essential for telecommunication providers, network installers, and infrastructure projects.

This high-quality CAD blueprint provides the exact technical specifications for a robust, weatherproof enclosure. It is a vital resource for network engineers designing new routes or for fabricators manufacturing their own units. The drawing details the internal architecture, which is crucial for planning fiber routing, managing splice tray capacity, and ensuring correct cable bend radius is maintained. This specific design is optimized for durability and ease of use in the field, which is critical during installation and maintenance.

By downloading this file, you can integrate a precise model into your larger network topology plans, verify mounting clearances for aerial (pole) or subterranean (manhole) installation, and ensure your deployment is secure and reliable. This blueprint is invaluable for any project involving Fiber to the Home (FTTH), 5G backhaul, or enterprise data center connections. It provides all the necessary manufacturing details, from material thickness to seal specifications. Stop guessing on dimensions and ensure your optical network build-out is successful from the start.

الميزات الرئيسية:

  • Weatherproof Housing: Details the robust, high-impact enclosure design, including the main gasket and sealing mechanisms for a high IP rating (e.g., IP68).
  • Cable Entry Ports: Shows the configuration of multiple entry/exit ports for main and drop cables, including gland seal details.
  • Splice Tray Management: Illustrates the internal fiber routing and the stackable splice tray holder for organizing and protecting splices.
  • Mounting Provisions: Includes a detailed bolt-down pattern for wall-mount or pole-mount bracket integration.
  • Material Specification: Based on durable, UV-stabilized polymers (like ABS or Polycarbonate) for long-term outdoor deployment.
