Master the fundamentals of precision machining with our detailed technical drawing of an End Mill Cutter. As one of the most versatile and widely used tools in CNC milling, the end mill is essential for profiling, slotting, and finishing operations. This free drawing is an invaluable resource for CNC machinists, mechanical engineers, and students who want to understand the critical geometry that defines a high-performance cutting tool.
This is not just a simple illustration; it is a complete technical blueprint that specifies the crucial angles and dimensions of the cutter. Use this drawing to deepen your understanding of tool design, create accurate tool profiles for your CAM software, or as a reference for grinding custom cutters. Download this professional drawing for free to enhance your manufacturing knowledge and improve your machining outcomes.
الميزات الرئيسية:
- Flute and Helix Geometry: The drawing details a standard 4-flute design, clearly specifying the helix angle which is critical for efficient chip evacuation and a smooth cutting action.
- Cutting Edge Geometry: Provides precise specifications for the primary and secondary clearance angles on the cutting edges, which are essential for reducing friction and maximizing tool life.
- Shank and Dimensions: Features a standard straight shank with a Weldon flat for secure clamping, along with critical dimensions like cutting diameter, length of cut, and overall length.
- Center-Cutting End Face: The design illustrates a center-cutting end geometry, allowing the tool to be used for plunging directly into the material, in addition to side milling.
