Are you a mechanic, fabricator, or serious DIYer who needs your most-used tools to be organized and mobile? Our Tool Cart (Five Drawers, One Door) drawing is the complete blueprint for building the most versatile and popular style of workshop cart. This is the classic design trusted by professionals, engineered to move with you and keep everything you need within arm’s reach.
This specific layout is the perfect balance of organization and bulk storage. The five drawers are ideal for systematically organizing all your hand tools—wrenches, sockets, screwdrivers, and precision instruments. The single-door cabinet on the side provides a large, open space perfect for storing bulky items like power tool cases, spray cans, or battery chargers.
This downloadable CAD file is a complete, fabrication-ready guide. It provides all the details to build a heavy-duty cart that is far superior to flimsy, store-bought models. It includes all sheet metal flat patterns, bend lines, assembly views, and a full bill of materials, from the heavy-gauge steel recommendations to the specific ball-bearing slides, casters, and locking hardware.
Características principales:
- Hybrid Storage Design: The perfect combination of five (5) drawers for fine-tool organization and one (1) large bulk storage cabinet for power tools and supplies.
- Heavy-Duty Mobility: The drawing details a reinforced base and mounting plates for heavy-duty swivel and locking casters, ensuring it rolls smoothly even when fully loaded.
- Full-Extension Drawers: Specifies the integration of high-quality, ball-bearing drawer slides, providing smooth operation and full access to your tools.
- Secure Locking System: Includes plans for a central locking mechanism that secures all drawers, plus a separate lock for the side cabinet, keeping your gear safe.
- Fabrication-Ready Plans: A complete package with all cut lists, flat patterns, bend details, and assembly instructions to build a professional-grade cart.
