Enhance the safety and stability of your mobile equipment with our Trolley Locking Structure CAD drawing. In high-traffic warehouse environments or precision assembly lines, preventing unintended movement of trolleys and carts is a critical safety requirement. This technical чертеж provides a detailed blueprint for a robust floor-locking or rail-engagement mechanism designed to immobilize mobile units with a single foot-actuated or pneumatic stroke.
This download offers an in-depth look at the linkage geometry that provides a high clamping force while requiring minimal operator effort. The layout includes specifications for the high-friction plunger pads and the spring-return system that ensures the lock is fully retracted when not in use. By studying this чертеж, you can analyze how to integrate the locking structure into various chassis types, ensuring that the load is distributed evenly to prevent tipping. At MechStream, we focus on providing reliable, “shop-floor-proven” mechanical solutions that bridge the gap between mobility and stability. Download this blueprint today to secure your rolling stock and improve workplace ergonomics.
Ключевые особенности:
- Positive Engagement Mechanism: Features a toggle-action linkage that “over-centers” to ensure the lock remains engaged even under heavy vibration.
- Adjustable Plunger Height: Includes a threaded adjustment system to compensate for uneven floors or varying wheel wear.
- Heavy-Duty High-Friction Pad: Specifications for non-slip, non-marring rubber or polyurethane pads that grip various floor surfaces securely.
- Ergonomic Foot-Pedal Operation: Designed for rapid engagement and disengagement without the operator having to bend over or use hand tools.
- Universal Mounting Flange: Features a standardized hole pattern compatible with most industrial casters and trolley frames.
