The Trolley Design 2 model is an absolutely essential upgrade for internal logistics, featuring a multi-level structure optimized for organizing, separating, and transporting diverse components and tools. This enhanced trolley is critical for production lines utilizing kitting or batch assembly processes, where quick visual confirmation and separate storage tiers are required. MechStream is delighted to offer a detailed, technical drawing of this improved multi-level utility cart as a vital free download. This comprehensive CAD resource provides the exact dimensions, shelf spacing, and structural reinforcement details necessary for superior manufacturing and deployment.

This high-quality free drawing is an indispensable tool for mechanical and industrial engineers focused on lean principles and organizational efficiency. It clearly outlines the structural frame, the precise vertical positioning of shelves, and includes provisions for small bins or dividers (enhancing its sorting capability). The multi-tier design, as detailed in this model, is essential for carrying complex BOMs (Bill of Materials) while ensuring components do not shift or contaminate each other. By leveraging this precision drawing, you can confidently estimate component needs, verify structural strength under distributed loads, and standardize your advanced assembly support equipment. Download your powerful Multi-Tier Trolley Design 2 drawing today, exclusively from MechStream, and master your detailed logistics designs.

Key Features:

  • Multi-Tiered Shelving: Specifies the dimensions and vertical clearances of multiple shelves for organized and separated parts storage.
  • Structural Cross-Bracing: Details the frame reinforcement necessary to ensure stability for distributed loads across multiple levels.
  • Caster and Mobility Plan: Includes mounting points for robust, high-load casters (often with integrated brakes) for safe movement on the factory floor.
  • Kitting Optimization: The shelf dimensions are compatible with standard industrial bins and trays, ideal for assembly line kitting operations.
  • Instant Free Access: Obtain this essential, professional-grade material handling drawing at no cost for immediate use in mechanical and layout planning software.
