Bolt Tensile Strength Check Calculator

The Bolt Tensile Strength Check Calculator is a professional engineering tool designed to evaluate the tensile strength and load-bearing capacity of bolts under different working conditions. By analyzing key parameters such as bolt diameter, material strength, applied tensile load, and safety factor, it helps engineers verify whether a bolt can safely withstand the required force. The Bolt Tensile Strength Check Calculator supports fastener selection, mechanical design, and structural safety evaluation while reducing the risks of bolt fracture, excessive stress, and connection failure.

Bolt Tensile Strength Check Calculator | Bolt Load Capacity & Safety Factor

Input parameters

1 Bolt geometry

Bolt diameter ?Nominal major diameter d. For metric bolts this is the M-size (12 mm for M12). For UN bolts enter the nominal inch size. Used to estimate tensile stress area At.

Thread pitch ?Metric: distance between threads in mm (M12 coarse = 1.75 mm). Imperial: threads per inch (TPI), e.g. 13 for ½″-13 UNC. Required to auto-calculate tensile stress area.

Tensile stress area A_t ?Effective tensile area of the threaded section. Auto-calculated from diameter and pitch, or enter a catalog / ISO 898 value manually. Stress is σ = F / At.

mm²

Enter A_t manually

Metric: A_t = π/4 × (d − 0.9382 p)². UN: A_t = π/4 × (d − 0.9743/n)². ISO 898-1 M12 coarse is 84.3 mm².

2 Material strength

Bolt material grade ?ISO 898-1 property classes use nominal Sut = class × 100 MPa and Sy = second digit × Sut / 10. Stainless uses A2-70 (700 / 450 MPa). Choose Custom Material to type catalog values.

Ultimate tensile strength S_ut ?Minimum ultimate tensile strength of the bolt. Grade 10.9 nominal Sut is 1000 MPa. Maximum tensile capacity Ft = At × Sut.

MPa

Yield strength S_y ?Minimum yield or 0.2% proof stress. Grade 10.9 nominal Sy is 900 MPa. Allowable stress Sa = Sy / design safety factor.

MPa

3 Applied tensile load

Applied tensile load ?External pulling force on the joint. For multiple bolts this is the total load; the calculator splits it equally as F / n. Do not enter a negative or zero value.

Number of bolts ?Bolts assumed to share the tensile load equally. Load per bolt = total load / n. Eccentric patterns and prying can increase the peak bolt load.

Design safety factor ?Divides yield strength to obtain allowable tensile stress Sa = Sy / n. Default 2.0 is a common static-design starting point. Critical or fatigue joints often need a higher factor from the governing standard.

Allowable tensile stress S_a = S_y / n. This Bolt Safety Factor Calculator then reports Safety Factor = allowable load / applied load per bolt.

Calculated results

Bolt tensile stress

—

σ = F / A_t

Safety factor

—

Allowable load / applied load

Safety factor gauge

—

Fa / F per bolt (scale 0–4)

Load utilization percentage —

≤ 85% allowable 85–100% warning > 100% failure risk

Strength comparison chart

Applied stress σ

—

Allowable S_a

—

Yield S_y

—

Ultimate S_ut

—

Maximum tensile capacity

—

F_t = A_t × S_ut

Allowable tensile load

—

F_a = A_t × S_a

Load per bolt

—

F / n

Tensile stress area

—

from d and pitch

Allowable stress S_a

—

S_y / design n

Yield strength

—

material S_y

Ultimate strength

—

material S_ut

SF vs yield

—

S_y / σ

SF vs ultimate

—

S_ut / σ
